Description :
Designed for maximum simplicity when setting up hauling or load deviation systems:
– the rope can be easily installed even when the pulley is connected to the anchor
– the pulley always stays attached to its connector, limiting the risk of losing the device
Especially suited for handling heavy loads:
– large diameter sheave mounted on sealed ball bearings for excellent efficiency
– side plate locks when loaded and prevents opening of the pulley during use

Specifications :
Weight: 205 g
Certification(s): CE EN 12278, EAC, NFPA 1983 Technical Use
Material(s): aluminum, nylon
Min. rope diameter: 7 mm
Max. rope diameter: 13 mm
Sheave type: sealed ball bearings
Sheave diameter: 38 mm
Maximum working load: 2 x 2,5 = 5 kN
Breaking strength: 2 x 11 = 22 kN
Efficiency: 95 %
